15.6 inch High-end WiFi Self Service Order Payment Machine with App
Features for Self Service Order Payment Machine
15.6 inch dual-screen self service checkout terminal distinctive appearance,high-end fashion
With NFC Scanner,QR Scanner,thermal printer
Installation methods:Desktop or Wall-mounted
Specifications for WiFi order payment device
| Model | MG-156HT-A |
| Camera | Type | 3D Opical Modules Camera |
| Working distance | 0.28-1m for close distance,0.4-2m for long distance |
| Main function | 1. Accurate synchronization of color pictures and depth pictures |
| 2. Support long-term stable work |
| 3. Support USB power supply |
| 4. Support UVC protocol |
| 5. Generate close-distance depth pictures |
| 6. Wide dynamic, low illumination |
| Screen | Size | Main screen: 15.6-inch LCD, secondary screen: 15.6-inch LCD,
support dual-screen different display |
| Resolution | 1920*1080,1920*1080 |
| Touch | Dual screen dual touch |
| Processor | CPU | RK3568 Quad-core highest frequency 2.0GHz |
| Storage | Standard 2GB (4G optional) RAM + 16GB (8/32/64G optional) ROM |
| System | OS | Android 11.0 |
| Interface | network module | Support Ethernet, wireless (WIFI), Bluetooth, 4G full Netcom |
| Audio | Support 4R3W speakers |
| USB | 1* RJ12 , 1* RJ11 cash drawer |
| Keys | Physical keys, including volume +/- key, reset key, power key,UBOOT upgrade key, a total of 5 keys |
| Wired network interface | 1-way RJ45 Ethernet socket |
| SIM slot | Nano SIM Card |
| Function | NFC | Support a variety of card payment |
| Priner | 58/80mm thermal printer |
| Scanner | Support common barcode and QR code, support QR Code, EAN-13/UPC-A, UPC-E, EAN-8, Code 128, Code39, Interleaved 2of5, etc. |
| Indicator Light | Red/green |
| General parameters | Power supply | Adapter input: 100-240V～50/60Hz 2.5A MAX output: 12V ⎓ 7.5A |
| Working temperature | 0℃~50℃ |
| Storage temperature | -20℃~60℃ |
| Installation method | Bracket base installation, wall-mounted screw fixing |
| Device dimension | 397*250*605mm(L*W*H) |
| EMC | Static immunity | Contact discharge: 4KV;Air discharge: 8KV |
It is new-design fashion self service order payment machine with dual screen dual touch,which support Android 11.0.
The use of self service machine offered in places with supermarket,hotels ect.
3D Opical Modules Camera for 15.6inch self service payment vending machine
It support USB power supply and Support UVC protocol.And it generates close-distance depth pictures.
Screen for self service payment vending device
IMain screen is 15.6-inch LCD, secondary screen is15.6-inch LCD, which support dual-screen different display.
